SDEC generator sets are industrial-grade power generation equipment developed and manufactured by Shanghai Diesel Engine Co., Ltd. (SDEC), a company founded in 1947. SDEC’s entire product line is self-developed and self-produced. SDEC’s full range covers power from 10kW to 2900kW, encompassing both diesel and gas engine models, supporting multiple application scenarios including land and sea, and compatible with global 50/60Hz power grid standards. With high power reserves, ultra-low fuel consumption, strong adaptability to extreme environments, and stable power supply performance, they are widely used in data centers, precision manufacturing, mining and oil fields, infrastructure projects, commercial buildings, and other fields, making them a cost-effective mainstay power generation equipment for overseas projects.
| 375kVA SDEC Generator Set Parameters： | |
|---|---|
| Model | SDEC375GST |
| Rated Power | 375kVA |
| Rated Power Factor | COSΦ=0.8（Lagging） |
| Rated Output Voltage | 400V/230V |
| Dimensions | 3070*1100*1650mm |
| Rated Frequency/Speed | 50Hz/1500rpm |
| Weight | 1640KG |
| Diesel Engine Technical Parameters： | |
| Brand | SDEC |
| Model | SC12E480D2 |
| Rated Power | 403kVA |
| Number of Cylinders | 6.L |
| Bore × Stroke | 128mm*153mm |
| Governor Type | Electronic Governing |
| Alternator Parameters： | |
| Brand | Stamford |
| Model | HC434FS |
| Rated Power | 375kVA |
| Phase & Wires | 3-Phase 4-Wire |
| Protection Class | IP23 |
| Insulation Class | Class H |
| Excitation Method | Brushless Self-Excitation |
| Standard Configuration of Generator Set： | |
| ØDirect injection internal combustion engine (diesel)； | |
| ØAC synchronous generator (single bearing)； | |
| ØRadiator suitable for ambient temperatures of 40°C–50°C,belt-driven cooling fan, fan safety | |
| guard； | |
| ØGenerator output air circuit breaker, standard control panel； | |
| ØSteel-mounted common base (including vibration-damping rubber pads)； | |
| ØDry-type air filter, fuel filter, lubricating oil filter, starting motor, and self-charging | |
| alternator； | |
| ØStarting battery and battery starting connection cables； | |
| ØIndustrial-grade silencer with connecting standard parts | |
| ØAccompanying documents: Original technical documents of the engine and generator, | |
| generator set operation manual, test report, etc. | |
| Optional Accessories： | |
| ØEngine oil, diesel, jacket water, and anti-condensation heaters | |
| ØSeparated daily fuel tank, integrated base fuel tank | |
| ØBattery float charger | |
| ØRainproof canopy (enclosure) | |
| ØSelf-protection and auto-start control panel | |
| ØSilent-type canopy (enclosure) | |
| ØControl panel with “three-remote” function (remote measurement, remote signaling, remote | |
| control) | |
| ØSilent-type mobile power station (trailer-mounted silent enclosure) | |
| ØATS automatic load transfer panel | |
| ØMobile trailer-type power station (trailer-mounted enclosure) | |
Due to continuous model updates, the information above is provided for reference only and shall not be deemed the basis for final delivery. The company reserves the right to make final modifications without further notice.
